Honda TRX500 TRX500FM 2012 Forman Manual Shift 4 Wheel Drive ATV QUAD

Honda TRX500FM ATV 2012 model. This ATV is our ex demo machine. and has had very light use. covering only 339KM. This machine does have the usual marks / scratches as can only be expected with a used ATV. 8 Months Honda warranty remaining.
Year 2012
Model TRX500FM Foreman
Category Multi Purpose
Engine type 4-stroke
Cylinder 1
Valvetrain OHV. 2 valves
Cooling system Air-Cooled
Displacement (cc) 475. 0
Bore (mm) 92. 0
Stroke (mm) 71. 5
Compression ratio 9. 5:1
Fuel system PGM-FI electronic fuel injection
Starter Electric
Gearbox speed 5
Gearbox operation Manual with automatic clutch and reverse
Drive system 2WD/4WD
Final drive Shaft
Front suspension type Independent double wishbone. hydraulic shocks
Front suspension travel (mm) 171
Rear suspension type Swingarm with hydraulic shocks
Rear suspension travel (mm) 174
Front brakes Dual 196-mm hydraulic discs
Rear brakes Sealed drum
Front tires width (inch) 8
Front tires height (inch) 25
Front tires inner diameter (inch) 12
Rear tires width (inch) 10
Rear tires height (inch) 25
Rear tires inner diameter (inch) 12
Length (mm) 2127
Width (mm) 1205
Weelbase (mm) 1281
Seat height (mm) 882
Ground clearance (mm) 194
Weight (kg) 284
Fuel capacity (L) 15. 0
Speedometer std
Odometer std
